Cilium CNI для enterprise Kubernetes: eBPF networking без sidecar'ов

Меня зовут Семёнов Евгений Сергеевич, директор АйТи Фреш. Cilium — default CNI для major cloud providers в 2026, использует eBPF для high-performance networking без kernel bypass. L3/L4/L7 load balancing, network policies, service mesh capabilities — всё на уровне kernel. Рассказываю о миграции с Calico на Cilium для production кластера с 200+ подами.

Cilium vs традиционные CNI

Cilium революционизирует Kubernetes networking через eBPF:

• eBPF-based — работает в kernel space, no iptables overhead
• L7 Load Balancing — HTTP/gRPC load balancing без sidecar'ов
• Identity-based Security — network policies по service identity
• Multi-cluster Networking — Cluster Mesh для multi-region
• Hubble Observability — network flows visibility из коробки

Установка Cilium в existing кластер

# 1. Install Cilium CLI
CILIUM_CLI_VERSION=$(curl -s https://raw.githubusercontent.com/cilium/cilium-cli/main/stable.txt)
curl -L --fail --remote-name-all https://github.com/cilium/cilium-cli/releases/download/${CILIUM_CLI_VERSION}/cilium-linux-amd64.tar.gz
sudo tar xzvfC cilium-linux-amd64.tar.gz /usr/local/bin

# 2. Install Cilium with enterprise features
cilium install \
  --helm-set kubeProxyReplacement=strict \
  --helm-set operator.replicas=2 \
  --helm-set hubble.enabled=true \
  --helm-set hubble.relay.enabled=true \
  --helm-set hubble.ui.enabled=true \
  --helm-set prometheus.enabled=true \
  --helm-set operator.prometheus.enabled=true

# 3. Verify installation
cilium status --wait
cilium connectivity test

Enterprise network policies с Cilium

# L3/L4 Network Policy
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: backend-policy
  namespace: production
spec:
  endpointSelector:
    matchLabels:
      app: backend
  ingress:
  - fromEndpoints:
    - matchLabels:
        app: frontend
    toPorts:
    - ports:
      - port: "8080"
        protocol: TCP
  - fromEndpoints:
    - matchLabels:
        app: prometheus
    toPorts:
    - ports:
      - port: "9090"
        protocol: TCP
        rules:
          http:
          - method: "GET"
            path: "/metrics"

# L7 HTTP Policy
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: api-l7-policy
spec:
  endpointSelector:
    matchLabels:
      app: api-server
  ingress:
  - fromEndpoints:
    - matchLabels:
        app: web-frontend
    toPorts:
    - ports:
      - port: "80"
        protocol: TCP
        rules:
          http:
          - method: "GET"
            path: "/api/v1/.*"
          - method: "POST"
            path: "/api/v1/users"
            headers:
            - "Content-Type: application/json"

Service Mesh без sidecar'ов

Cilium Service Mesh обеспечивает L7 capabilities без Envoy sidecar'ов:

# Enable Cilium Service Mesh
helm upgrade cilium cilium/cilium \
  --namespace kube-system \
  --reuse-values \
  --set serviceAccount.name=cilium \
  --set envoy.enabled=true

# L7 Load Balancing configuration
apiVersion: cilium.io/v2alpha1
kind: CiliumL2LoadBalancer
metadata:
  name: api-lb
spec:
  selector:
    matchLabels:
      app: api-server
  loadBalancer:
    algorithm: round_robin
    healthCheck:
      path: /health
      port: 8080
      interval: 10s
  ports:
  - protocol: HTTP
    port: 80
    backend: 8080

Monitoring Cilium с Hubble

# Enable Hubble observability
hubble observe --namespace production
hubble observe --protocol http

# Grafana dashboard queries
# Network policy drops
rate(hubble_drop_total{reason="Policy denied"}[5m])

# L7 HTTP requests by service
rate(hubble_http_requests_total[5m]) by (source_app, destination_app)

# Cilium eBPF map usage
cilium_bpf_map_capacity{map_name!=""}
